7.11 Measurement Data
7.11.1 Instantaneous Value Measurement
Normal measurement data
Instantaneous Values
Each Phase/CH nter-phase Average Σ Each Load
Measurement Function
Voltage rms value
Current rms value
Active power
Reactive power
Apparent power
Power factor
Phase angle
Frequency
DC voltage (option)
Legend : measured data available : measured data not available
Harmonic measurement data
Instantaneous Values
Each Phase Σ Each Load
Selected Order
*1
Measurement Function
Voltage rms value
Voltage content
Voltage phase angle
Current rms value
Current content
Current phase angle
Power value
Power content
Power phase angle
Voltage THD
Current THD
*1
Legend : measured data available : measured data not available
*1: Numerical data of any of the 1st to 50th.
*2: All orders means numerical data of all objective waveforms including the fundamental
wave and all harmonics.
All Orders
*2
