5.3 Ranges and Number of Digits
This section describes the voltage, current, power, and electric energy ranges.
● Voltage Ranges
150/300/600/1000 V
● Current Ranges
Current ranges vary depending on the clamp-on probe to be used.
Clamp-on Probe
96036 200mA 500mA 1A 2A
96033 5A 10A 20A 50A
96030 20A 50A 100A 200A
96031 50A 100A 200A 500A
96032 200A 500A 1000A
96034_1 300A 750A 1500A 3000A
96034_2 200A 500A 1000A 2000A
96034_3 100A 200A 500A 1000A
96035_1 300A 750A 1500A 3000A
96035_2 30A 75A 150A 300A
96034 or 96035: Current range is selected using the switch on a clamp-on probe.
Current Range
● Active and Reactive Power Ranges
The active and reactive power ranges are determined as shown below
depending on the voltage range, current range, and/or wiring system (wiring).
Wiring System (Wiring)
1P2W
1P3W
1P3W3I
3P3W2I
3P3W3I
3P3W+1P3W*
3P4W
3P4W4I
*: Scott connection
Power Range
Voltage range ⫻ current range
Voltage range ⫻ current range ⫻ 2
Voltage range ⫻ current range ⫻ 3
