1.2 Ethernet Interface Features and Specifications
Ethernet Interface Features
Reception Features
You can use the reception feature to specify the same settings that you specify through the panel
keys and the touch panel.
Receives output requests for measured and computed data, panel setting data, and error codes.
Transmission Features
The instrument can transmit measured and computed data.
The instrument can transmit panel setting data and the status byte.
The instrument can transmit error codes when errors occur.
Ethernet Interface Specifications
Number of ports: 1
Electrical and mechanical specifications: IEEE802.3
Data rate: 100 Mbps max.
Communication protocol: TCP/IP
Connector: RJ-45
Data Transfer Rate
The following table contains approximations of how much time it takes for the instrument to transmit
waveform data.
Number of Data Points Byte Data Word Data ASCII Data
1000 Approx. 1 ms Approx. 1 ms Approx. 30 ms
10000 Approx. 1 ms Approx. 2 ms Approx. 300 ms
100000 Approx. 10 ms Approx. 11 ms Approx. 3 s
1000000 Approx. 100 ms Approx. 125 ms Approx. 30 s
