YOKOGAWA DL350 User Manual

4-120
IM DL350-17EN
4.18 IMAGe Group
The commands in this group deal with saving screen capture data. You can make the same settings and queries that
you can by using Save/Load > Save Key Setup > Save Image in the top menu. In addition, you can execute the
same operation that you can by using the SAVE key on the front panel.
:IMAGe:SAVE:DRIVe
Function Sets the output destination medium.
Syntax
:IMAGe:SAVE:DRIVe {NETWork|SD|
USB,<NRf>}
Example
:IMAGe:SAVE:DRIVe USB,0
Description See the description of the
:FILE[:DIRectory]:DRIVe command.
:IMAGe:SAVE:NAME
Function Sets or queries the name of the file that will be
saved.
Syntax
:IMAGe:SAVE:NAME {<Filename>}
:IMAGe:SAVE:NAME?
Example
:IMAGE:SAVE:NAME "ABC"
:IMAGe:SAVE:NAME? -> :IMAGe:SAVE:NAME
:IMAGe:SAVE:PATH?
Function Queries the current directory.
Example
:IMAGE:SAVE:PATH?
-> :IMAGE:SAVE:PATH "Path=USB,0"
:IMAGe:SEND?
Function Queries the screen capture data.
Syntax
:IMAGe:SEND?
Description The screen capture data is output as block data.
:IMAGe:TONE
Function Sets or queries the color tone of the screen
capture data that will be saved.
Description
:IMAGe:TONE {COLor|GRAY|OFF|REVerse}
:IMAGe:TONE?
Example
:IMAGE:TONE REVERSE
:IMAGE:TONE? -> :IMAGE:TONE REVERSE
:IMAGe?
Function Queries all screen capture data output settings.
Syntax
:IMAGe?
:IMAGe:BACKground
Function Sets or queries the screen capture background
(png).
Syntax
:IMAGe:BACKground {NORMal|
TRANsparent}
:IMAGe:BACKground?
Example
:IMAGE:BACKGROUND NORMAL
:IMAGE:BACKGROUND?
-> :IMAGE:BACKGROUND NORMAL
:IMAGe:EXECute
Function Saves the screen capture data.
Syntax
:IMAGe:EXECute
Example
:IMAGE:EXECUTE
:IMAGe:FORMat
Function Sets or queries the screen capture output format.
Syntax
:IMAGe:FORMat {BMP|JPEG|PNG}
:IMAGe:FORMat?
Example
:IMAGE:FORMAT PNG
:IMAGE:FORMAT? -> :IMAGE:FORMAT PNG
:IMAGe:SAVE?
Function Queries all file output settings.
Syntax
:IMAGe:SAVE?
:IMAGe:SAVE:ANAMing
Function Sets or queries the on/off setting of the auto
naming feature for saving files.
Syntax
:IMAGe:SAVE:ANAMing {DATE|
NUMBering|OFF}
:IMAGe:SAVE:ANAMing?
Example
:IMAGE:SAVE:ANAMING NUMBERING
:IMAGE:SAVE:ANAMING?
-> :IMAGE:SAVE:ANAMING NUMBERING
:IMAGe:SAVE:CDIRectory
Function Changes the output destination directory.
Syntax
:IMAGe:SAVE:CDIRectory {<String>}
<String> = Up to 16 characters
Example
:IMAGW:SAVE:
CDIRECTORY "20170618_000"
