4.10 DISPlay Group
The commands in this group deal with the screen display. You can make the same settings and queries that you can
by using Display in the top menu.
:DISPlay:{CHANnel<x1>[:SCHannel<x2>]
|MATH<x3>}:COLor
Function Sets or queries a waveform color.
Syntax For channels that do not have sub channels or for
math channels:
:DISPlay:{CHANnel<x1>|MATH<x3>}:
COLor {BLUE|BGReen|CYAN|DBLue|GRAY|
GREen|LBLue|LGReen|MAGenta|MGReen|
ORANge|PINK|PURPle|RED|SPINk|
YELLow}
:DISPlay:{CHANnel<x1>|MATH<x3>}:
COLor?
For channels that have sub channels:
:DISPlay:CHANnel<x1>:SCHannel<x2>:
COLor {BLUE|BGReen|CYAN|DBLue|GRAY|
GREen|LBLue|LGReen|MAGenta|MGReen|
ORANge|PINK|PURPle|RED|SPINk|
YELLow}
:DISPlay:CHANnel<x1>:SCHannel<x2>:
COLor?
<x1> = 1 to 7
<x2> = 1 to 60
<x3> = 1, 2
Example
:DISPLAY:CHANNEL1:COLOR YELLOW
:DISPLAY:CHANNEL1:COLOR?
-> :DISPLAY:CHANNEL1:COLOR YELLOW
Description The FFT1 and FFT2 waveforms are the same
color as the MATH1 and MATH2 waveforms,
respectively.
:DISPlay:COLor:BASecolor
Function Sets or queries the color theme (base color) of
the screen.
Syntax
:DISPlay:COLor:BASecolor {BLACk|
WHITe}
:DISPlay:COLor:BASecolor?
Example
:DISPLAY:COLOR:BASECOLOR BLACK
:DISPLAY:COLOR:BASECOLOR?
-> :DISPLAY:COLOR:BASECOLOR BLACK
:DISPlay:DECimation
Function Sets or queries the number of dots that are used
on the dot display.
Syntax
:DISPlay:DECimation {<NRf>}
:DISPlay:DECimation?
<NRf> = 2000, 100000
Example
:DISPLAY:DECIMATION 2000
:DISPLAY:DECIMATION?
-> :DISPLAY:DECIMATION 2000
:DISPlay?
Function Queries all display settings.
Syntax
:DISPlay?
:DISPlay:ACCumulate:MODE
Function Sets or queries the accumulated waveform mode.
Syntax
:DISPlay:ACCumulate:MODE {OFF|ON}
:DISPlay:ACCumulate:MODE?
Example
:DISPLAY:ACCUMULATE:MODE ON
:DISPLAY:ACCUMULATE:MODE?
-> :DISPLAY:ACCUMULATE:MODE ON
Description This command is valid in scope mode.
:DISPlay:AGRoup (Auto Grouping)
Function You can also automatically reassign just the
channels (CH, Math, and sub channels) whose
displays are turned on to Gr.1 to Gr.4 and DMM.
Syntax
:DISPlay:AGRoup
Example
:DISPLAY:AGROUP
:DISPlay:CINFormation?
Function Sets or queries all channel information display
settings.
Syntax
:DISPlay:CINFormation?
:DISPlay:CINFormation:MODE
Function Sets or queries whether the channel information
display is displayed.
Syntax
:DISPlay:CINFormation:
MODE {<Boolean>}
:DISPlay:CINFormation:MODE?
Example
:DISPLAY:CINFORMATION:MODE 1
:DISPLAY:CINFORMATION:MODE?
-> :DISPLAY:CINFORMATION:MODE 1
:DISPlay:CINFormation:TYPE
Function Sets or queries the contents of the channel
information display.
Syntax
:DISPlay:CINFormation:
TYPE {INFO|MONitor}
:DISPlay:CINFormation:TYPE?
Example
:DISPLAY:CINFORMATION:TYPE MONITOR
:DISPLAY:CINFORMATION:TYPE?
-> :DISPLAY:CINFORMATION:TYPE
MONITOR
