4.33 TRIGger Group
The commands in this group deal with triggers. You can make the same settings and queries that you can by using
the trigger settings under Acquire in the top menu.
:TRIGger:ACTion:IMAGe?
Function Queries all settings for saving screen captures as
an action.
Syntax
:TRIGger:ACTion:IMAGe?
:TRIGger:ACTion:IMAGe[:MODE]
Function Sets or queries whether a screen capture is
saved to the storage medium as an action.
Syntax
:TRIGger:ACTion:IMAGe[:
MODE] {<Boolean>}
:TRIGger:ACTion:IMAGe?
Example
:TRIGGER:ACTION:IMAGE:MODE ON
:TRIGGER:ACTION:IMAGE:MODE?
-> :TRIGGER:ACTION:IMAGE:MODE 1
:TRIGger:ACTion:IMAGe:CDIRectory
Function Sets or queries the current directory on the
storage medium where screen captures are
saved to as an action.
Syntax
:TRIGger:ACTion:IMAGe:
CDIRectory {<String>}
:TRIGger:ACTion:IMAGe:CDIRectory?
<String> = Up to 16 characters
Example
:TRIGGER*ACTION:IMAGE:
CDIRECTORY "NO_1"
:TRIGGER*ACTION:IMAGE:CDIRECTORY?
-> :TRIGGER*ACTION:IMAGE:
CDIRECTORY "NO_1"
:TRIGger:ACTion:IMAGe:DRIVe
Function Sets the storage medium that screen captures
are saved to as an action.
Syntax
:TRIGger:ACTion:IMAGe:
DRIVe {NETWork|SD|USB,<NRf>}
<NRf> = 1, 2
Example
:TRIGGER:ACTION:IMAG:DRIVE SD
:TRIGger:ACTion:IMAGe:PATH?
Function Queries the path on the storage medium where
screen captures are saved to as an action.
Syntax
:TRIGger:ACTion:IMAGe:PATH?
Example
:TRIGGER:ACTION:IMAGE:PATH?
-> :TRIGGER:ACTION:IMAGE:
PATH "Path=SD/***"
:TRIGger?
Function Queries all trigger settings.
Syntax
:TRIGger?
:TRIGger:ACTion?
Function Queries all action settings.
Syntax
:TRIGger:ACTion?
:TRIGger:ACTion:BUZZer
Function Sets or queries whether a beep is sounded as an
action.
Syntax
:TRIGger:ACTion:BUZZer {<Boolean>}
:TRIGger:ACTion:BUZZer?
Example
:TRIGGER:ACTION:BUZZER ON
:TRIGGER:ACTION:BUZZER?
-> :TRIGGER:ACTION:BUZZER 1
:TRIGger:ACTion:FOLDer
Function Sets or queries whether a date folder is created
when waveform data or screen capture data is
saved to the storage medium when an action is
executed.
Syntax
:TRIGger:ACTion:FOLDer {<Boolean>}
Example
:TRIGGER:ACTION:FOLDER ON
:TRIGGER:ACTION:FOLDER?
-> :TRIGGER:ACTION:FOLDER 1
:TRIGger:ACTion:HCOPy
Function Sets or queries whether the screen image is
printed on the USB printer when an action is
executed.
Syntax
:TRIGger:ACTion:HCOPy {<Boolean>}
:TRIGger:ACTion:HCOPy?
Example
:TRIGGER:ACTION:HCOPY ON
:TRIGGER:ACTION:HCOPY?
-> :TRIGGER:ACTION:HCOPY 1
