4-28
IM DL350E-17EN
4.1 List of Commands
Command Function page
:WAVeform:OFFSet?
Queries the offset value used to convert the waveform data specified by the
:WAVeform:TRACe command to physical values.
4-168
:WAVeform:RANGe?
Queries the measurement range used to convert the waveform data
specified by the :WAVeform:TRACe command to physical values.
4-168
:WAVeform:RECord
Sets or queries the main waveform record number that WAVeform
commands will be applied to.
4-168
:WAVeform:RECord? MINimum
Queries the minimum record number in the acquisition memory (for the main
waveform).
4-168
:WAVeform:SEND?
Queries the waveform data (the main waveform measured data) specified by
the :WAVeform:TRACe command.
4-169
:WAVeform:SIGN?
Queries whether signs are included in the block data of the source waveform
data specified by :WAVeform:TRACe when the data is queried.
4-170
:WAVeform:SRATe? (Sample RATE)
Queries the sample rate of the waveform specified by the :WAVeform:TRACe
command.
4-170
:WAVeform:STARt
Sets or queries the start data point in the waveform specified by the
:WAVeform:TRACe command (the main waveform).
4-170
:WAVeform:TRACe
Sets or queries the waveform that WAVeform commands will be applied to. 4-170
:WAVeform:TRIGger?
Queries the trigger position of the record specified by the :WAVeform:RECord
command.
4-170
:WAVeform:TYPE?
Queries the acquisition mode of the source waveform. 4-170
XY Group
:XY?
Queries all X-Y waveform display settings. 4-171
:XY:DOTConnect
Sets or queries whether dot connect is ON or OFF for X-Y waveforms. 4-171
:XY:DECimation
Sets or queries the number of dots that X-Y waveforms use. 4-171
:XY:MARKer
Sets or queries whether X-Y pen markers are on. 4-171
:XY:TCLear (Trace Clear On
Start)
Sets or queries whether the X-Y waveform trace-clear-on-start feature is on. 4-171
:XY:WAVeform?
Queries all X-Y waveform settings. 4-171
:XY:WAVeform:DISPlay
Sets or queries whether the specified X-Y waveform is displayed. 4-171
:XY:WAVeform:XTRace
Sets or queries the channel that is assigned to the specified X-Y waveform’s
X axis.
4-171
:XY:WAVeform:YTRace
Sets or queries the channel that is assigned to the specified X-Y waveform’s
Y axis.
4-171
:XY:WINDow?
Queries all X-Y window settings. 4-172
:XY:WINDow:MODE
Sets or queries whether an X-Y window is displayed. 4-172
:XY:WINDow:TRANge
Sets or queries the T-Y waveform range to display in the X-Y window. 4-172
ZOOM Group
:ZOOM?
Queries all zoom settings. 4-173
:ZOOM:ASCRoll?
Queries all auto scroll settings. 4-173
:ZOOM:ASCRoll:JUMP
Moves the center position of the zoom box to the left or right edge of the
main window.
4-173
:ZOOM:ASCRoll:SPEed
Sets or queries the auto scroll speed of the zoom box. 4-173
:ZOOM:ASCRoll:STARt
Starts auto scrolling. 4-173
:ZOOM:ASCRoll:STOP
Stops auto scrolling. 4-173
:ZOOM:ASCRoll:TARGet
Sets or queries the zoom window that will be auto scrolled. 4-173
:ZOOM:FITMeasure
Moves the range on which automated measurement of waveform parameters
is performed to the zoom waveform display frame.
4-173
:ZOOM:FORMat<x>
Sets or queries the display format of the specified zoom waveform. 4-173
:ZOOM:GROup<x1>?
Queries all settings related to the specified group display of zoom
waveforms.
4-173
:ZOOM:GROUp<x1>:FORMat<x2>
Sets or queries the zoom waveform display format of the specified display
group.
4-173
:ZOOM:GROup<x1>:TRACe<x2>
Sets or queries whether the specified source waveform of the specified
group display of zoom waveforms is displayed.
4-173
:ZOOM:MAG<x>
Sets or queries the horizontal magnification of the specified zoom waveform. 4-174
:ZOOM:MAIN
Sets or queries the proportion of the main waveform display area that is used
when zooming waveforms.
4-174
:ZOOM:MODE<x>
Sets or queries whether the specified zoom waveform is displayed. 4-174
:ZOOM:MOVE
Moves the zoom box to the most recent data position. 4-174
:ZOOM:POSition<x>
Sets or queries the zoom position of the specified zoom waveform. 4-174
:ZOOM:TDIV<x>
Sets or queries the T/div value of the specified zoom waveform. 4-174
