4.3 ANALysis Group
The commands in this group deal with harmonic analysis. You can perform the same operations and make the same
settings and queries that you can by using Analysis > Harmonic in the top menu.
:ANALysis:HARMonic?
Function Queries all harmonic analysis settings.
Syntax
:ANALysis:HARMonic?
:ANALysis:HARMonic:FREQuency
(Frequency)
Function Sets or queries the frequency to be analyzed in
harmonic analysis.
Syntax
:ANALysis:HARMonic:FREQuency {<NRf>|
AUTO}
:ANALysis:HARMonic:FREQuency?
<NRf> = 50, 60
Example
:ANALYSIS:HARMONIC:FREQUENCY 50
:ANALYSIS:HARMONIC:FREQUENCY?
-> :ANALYSIS:HARMONIC:FREQUENCY 50
:ANALysis:HARMonic:GRAPh?
Function Queries all settings related to the harmonic
analysis result display.
Syntax
:ANALysis:HARMonic:GRAPh?
:ANALysis:HARMonic:GRAPh:DEGRee
Function Sets or queries the harmonic display mode of
harmonic analysis.
Syntax
:ANALysis:HARMonic:GRAPh:
DEGRee {ALL|EVEN|ODD}
:ANALysis:HARMonic:GRAPh:DEGRee?
Example
:ANALYSIS:HARMONIC:GRAPH:DEGREE ALL
:ANALYSIS:HARMONIC:GRAPH:DEGREE?
-> :ANALYSIS:HARMONIC:GRAPH:
DEGREE ALL
:ANALysis:HARMonic:GRAPh:DITem?
Function Sets or queries the displayed items of harmonic
analysis results.
Syntax
:ANALysis:HARMonic:GRAPh:DITem {LR1|
LR2|LR3|LR4|LR5|LR6|LR7|LR8|POWer}
:ANALysis:HARMonic:GRAPh:DITem?
Example
:ANALYSIS:HARMONIC:GRAPH:DITEM LR1
:ANALYSIS:HARMONIC:GRAPH:DITEM?
-> :ANALYSIS:HARMONIC:GRAPH:
DITEM LR1
:ANALysis:HARMonic:GRAPh:LSTart
Function Sets or queries the starting harmonic to be
displayed in the harmonic analysis display list of
harmonic analysis.
Syntax
:ANALysis:HARMonic:GRAPh:
LSTart {<NRf>}
:ANALysis:HARMonic:GRAPh:LSTart?
<NRf> = 1 to 40
Example
:ANALYSIS:HARMONIC:GRAPH:LSTART 1
:ANALYSIS:HARMONIC:GRAPH:LSTART?
-> :ANALYSIS:HARMONIC:GRAPH:LSTART 1
:ANALysis:HARMonic:GRAPh:MODE
Function Sets or queries the type of harmonic analysis
result display.
Syntax
:ANALysis:HARMonic:GRAPh:MODE {BAR|
LIST|OFF}
:ANALysis:HARMonic:GRAPh:MODE?
Example
:ANALYSIS:HARMONIC:GRAPH:MODE BAR
:ANALYSIS:HARMONIC:GRAPH:MODE?
-> :ANALYSIS:HARMONIC:GRAPH:MODE BAR
:ANALysis:HARMonic:GRAPh:PSCale
Function Sets or queries the phase angle scale of the
harmonic analysis result display.
Syntax
:ANALysis:HARMonic:GRAPh:
PSCale {DEGRee|RADian}
:ANALysis:HARMonic:GRAPh:PSCale?
Example
:ANALYSIS:HARMONIC:GRAPH:
PSCALE DEGREE
:ANALYSIS:HARMONIC:GRAPH:PSCALE?
-> :ANALYSIS:HARMONIC:GRAPH:
PSCALE DEGREE
:ANALysis:HARMonic:GRAPh:SCALe
Function Sets or queries the vertical scale when the
harmonic analysis result display is set to Bar.
Syntax
:ANALysis:HARMonic:GRAPh:
SCALe {LINear|LOG}
:ANALysis:HARMonic:GRAPh:SCALe?
Example
:ANALYSIS:HARMONIC:GRAPH:
SCALE LINEAR
:ANALYSIS:HARMONIC:GRAPH:SCALE?
-> :ANALYSIS:HARMONIC:GRAPH:
SCALE LINEAR
