YOKOGAWA DL350 User Manual

1-5
IM DL350-17EN
Ethernet Interface
1
2
3
4
5
App
Index
1.4 Configuring the Instrument Ethernet Settings
This section explains the settings listed below. You must configure these settings when controlling
the instrument remotely through an Ethernet interface.
• Network connection timeout period
Utility Network Menu
1.
On the waveform screen, tap MENU > Utility > Network > VXI11.
2.
Tap Time Out. Use the displayed input box to set the timeout period.
Timeout period
(Tap + or – to adjust.)
Configuring TCP/IP Settings
To use the Ethernet interface features, you must specify the following TCP/IP settings.
• IP address
• Subnet mask
• Default gateway
For details on how to specify these settings, see section 19.2, “Configuring TCP/IP Settings” in the
DL350 User’s Manual, IM DL350-02EN.
