JOHNSON CONTROLS
180
FORM 150.67-NM2
ISSUE DATE: 01/31/2019
SECTION 9 – SERVICE AND TROUBLESHOOTING
FIGURE 59 - MICROBOARD LAYOUT
TB5
TB1
TB6
TB7
TB8
TB9
TB10
J14
J13
J12
J15
J11
J10
J9
J8
J7
J6
J5
J3
I/O BOARD
IPU
BOARD
JP1
LD12721
