JOHNSON CONTROLS
23
SECTION 2 – PRODUCT DESCRIPTION
FORM 150.67-NM2
ISSUE DATE: 01/31/2019
2
LD11458a
FIGURE 4 - CONTROL/POWER PANEL COMPONENTS DUAL SYSTEM UNITS
TERMINAL BLOCK
FAN FUSES
CR1 / CR2
COMPRESSOR CONTACTS
TB1
CTB1
CONTROL / POWER PANEL COMPONENTS - YCAL0043 – 0066
