JOHNSON CONTROLS
193
SECTION 10 – MAINTENANCE
FORM 150.67-NM2
ISSUE DATE: 01/31/2019
10
BACNET AND MODBUS DATA
COMMUNICATION
Data can be read and in some cases modified using
a serial communication BACnet or Modbus network
connection. This information allows communications
of chiller operating parameters and external control
changes to setpoint, load limiting, and start/stop com-
mands.
In some cases, BACnet parameters may need to be
modified. Modification is accomplished by pressing
the PROGRAM, DOWN ARROW, DOWN ARROW,
DOWN ARROW, DOWN ARROW, and ENTER keys
in sequence. The list below shows the displays for the
values that may be modified:
DE MODIFIER ADDRESS
XXXXX
DE MODIFIER OFFSET
XX
P1 PROTOCOL
XXXXXX
P1 MANUAL MAC
ADDRESS XXX
P1 BAUD RATE
XXXXX
P1 PARITY
XXXXX
P1 STOP BITS
X
P2 PROTOCOL
XXXXXXXXXX
P2 MANUAL MAC
ADDRESS XXX
P2 BAUD RATE
XXXXX
P2 PARITY
XXXXX
P2 STOP BITS
X
REAL TIME ERROR ##
RESET 1 = YES, 0 = NO 0
The table below shows the real time error numbers and
a description of each.
TABLE 41 - REAL TIME ERROR NUMBERS
ERROR NUMBER
(##)
DESCRIPTION
0 ALL OK
1 DATUM TYPE OK TEST FAILED
2 ENGLISH TEXT TOO LONG
3 FLOATING POINT EXCEPTION
4 GET PACKET FAILED
5 GET TYPE FAILED
6 INVALID UNIT CONVERSION
7 INVALID HARDWARE SELECTION
8 REAL TIME FAULT
9 SPANISH TEXT TOO LONG
10 THREAD EXITED
11 THREAD FAILED
12 THREAD STALLED
13 IO BOARD RESET
14 BRAM INVALID
15 BACNET SETUP FAILED
