SECTION 5 – TECHNICAL DATA
FORM 150.67-NM2
ISSUE DATE: 01/31/2019
5
OPERATIONAL LIMITATIONS (SI)
TABLE 4 - TEMPERATURES AND FLOWS (SI)
YCAL
LEAVING WATER
TEMPERATURE ( °C)
COOLER FLOW (L/S) AIR ON CONDENSER ( °C)
MIN MAX MIN MAX MIN MAX
0019 4.4 12.8
1.1 4.3
-17.7 51.7
0022 4.4 12.8 1.3 5.3 -17.7 51.7
0028 4.4 12.8 1.9 7.6 -17.7 51.7
0033 4.4 12.8 2.2 8.6 -17.7 51.7
0043 4.4 12.8 2.5 12.6 -17.7 51.7
0046 4.4 12.8 2.5 12.6 -17.7 51.7
0052 4.4 12.8 2.5 12.6 -17.7 51.7
0056 4.4 12.8 3.8 18.9 -17.7 51.7
0066 4.4 12.8 3.8 18.9 -17.7 51.7
NOTES:
1. For leaving brine temperature below 40 °F (4.4 °C), contact your nearest YORK Ofce for application requirements.
2. For leaving water temperature higher than 55 °F (12.8 °C), contact the nearest YORK Ofce for application guidelines.
3. The evaporator is protected against freezing to -20 °F (-28.8 °C) with an electric heater as standard.
4. For operation at temperatures below 25 °F (-3.9 °C), the optional Low Ambient Kit will need to be installed on the system.
5. For operation at temperatures above 110 °F (43 °C), the optional High Ambient Kit will need to be installed on the system.
Voltage Limitations
The following voltage limitations are absolute and
operation beyond these limitations may cause serious
damage to the compressor.
TABLE 5 - VOLTAGE LIMITATIONS
UNIT POWER MIN. MAX.
200-3-60 180 220
230-3-60 207 253
380-3-60 355 415
460-3-60 414 506
575-3-60 517 633
Excessive ow will cause damage to the
cooler. Do not exceed max. cooler ow.
Special care should be taken when mul-
tiple chillers are fed by a single pump.
TABLE 6 - ETHYLENE AND PROPOLYNE GLYCOL CORRECTION FACTORS
ETHYLENE GLYCOL PROPYLENE GLYCOL
%
WEIGHT
TONS
COMPR
KW
GPM F/
TON
PRESS
DROP
FREEZE
PT
%
WEIGHT
TONS
COMPR
KW
GPM F/
TON
PRESS
DROP
FREEZE
PT
10.0 1.0 1.0 24.3 1.0 26.2 10.0 1.0 1.0 24.0 1.0 26.0
20.0 1.0 1.0 25.1 1.1 17.9 20.0 1.0 1.0 24.3 1.1 19.0
30.0 1.0 1.0 25.9 1.2 6.7 30.0 1.0 1.0 24.9 1.3 9.0
40.0 1.0 1.0 26.9 1.4 -8.1 40.0 1.0 1.0 25.6 1.4 -6.0
50.0 1.0 1.0 28.0 1.6 -28.9 50.0 0.9 1.0 26.6 1.7 -28.0
