York YCAL0043 Installation Operation & Maintenance

JOHNSON CONTROLS
46
FORM 150.67-NM2
ISSUE DATE: 01/31/2019
SECTION 5 – TECHNICAL DATA
PHYSICAL DATA (ENGLISH)
YCAL0019_ – YCAL0066_
50 HZ
TABLE 7 - PHYSICAL DATA (ENGLISH)
MODEL YCAL00 19 22 28 33 43 46 52 56 66
LENGTH, mm 2789 2789 2789 2789 3678 3678 3678 3678 3901
WIDTH, mm 1135 1135 1135 1135 2301 2301 2301 2301 2301
HEIGHT, mm 1171 1171 1270 1270 1214 1214 1590 1590 1590
NOMINAL RATINGS
Capacity, kW 45.6 55.0 75.3 84.3 109.6 115.8 136.0 165.9 195.6
Power Input, kW 14.5 18.0 23.7 25.7 34.7 36.6 42.0 52.5 63.0
EER, kW/kW 3.1 3.1 3.2 3.3 3.2 3.2 3.2 3.2 3.1
IPLV, kW/kW 4.6 5.0 4.4 4.7 4.9 4.9 4.7 4.7 4.8
REFRIGERANT R-410A
Number of Refrigerant Circuits 1 1 1 1 2 2 2 2 2
Refrig. Chg, Opt, R-410A (kg) ckt1/
ckt2
11.3 13.6 20.4 22.7 15.9/15.9 18.1/15.9 20.4/20.4 22.7/22.7 29.5/29.5
Oil Charge, liters, ckt1/ckt2 6.8 6.8 6.4 8.3 6.8/6.8 6.8/6.8 6.4/6.4 6.4/6.4 8.7/8.3
Shipping
Weight
Alum. Fin Coils, kgs 660 711 816 923 1334 1346 1438 1454 1858
Copper Fin Coils, kgs 724 808 909 1016 1497 1509 1666 1671 2133
Operating
Weight
Alum. Fin Coils, kgs 672 724 832 942 1346 1361 1455 1471 1879
Copper Fin Coils, kgs 737 821 923 1036 1508 1524 1683 1688 2154
NOMINAL COMPRESSOR CAPACITY
Compressor 1 8 10 15 15 10 12 13 15 20
Compressor 2 8 10 13 15 10 12 13 15 20
Compressor 3 – – – – – – – – –
Compressor 4 – – – – 10 10 13 15 15
Compressor 5 – – – – 10 10 13 15 15
Compressor 6 – – – – – – – – –
CONDENSER
Total Face Area m
2
3.2 3.2 4 4 8.1 8.1 10.8 10.8 11.9
Number of Rows Deep
Ckt. 1 2 3 3 3 2 2 3 3 3
Ckt. 2 – – – – 2 2 3 3 3
Fins per Inch 17 17 13 13 17 17 17 17 13
CONDENSER FANS, LOW SOUND
Number of Fans
Ckt. 1 2 2 2 2 2 2 2 2 2
Ckt. 2 – – – – 2 2 2 2 2
Fan Power kW/fan 0.3 0.3 0.9 0.9 0.8 0.8 1.0 1.0 1.0
Fan RPM 896 896 950 950 950 950 950 950 950
Total Chiller m
3
/h 16171 15101 34816 34816 67029 67029 73622 73622 73622
CONDENSER FANS, ULTRA QUIET
Number of Fans
Ckt. 1 – – 2 2 2 2 2 2 2
Ckt. 2 – – – – 2 2 2 2 2
Fan Power kW/fan – – 0.9 0.9 0.8 0.8 1.0 1.0 1.0
Fan RPM – – 690 690 690 690 690 690 690
Total Chiller m
3
/h – – 34816 34816 67029 67029 73622 73622 73622
EVAPORATOR
Water Volume, Liters 4.5 4.5 4.5 4.5 10.2 10.2 13.2 13.2 13.2
Max Water Side Pressure Barg 20.7 20.7 20.7 20.7 20.7 20.7 20.7 20.7 20.7
Max Refrig Side Pressure Barg 31 31 31 31 31 31 31 31 31
Min. Chiller Water Flow l/s 0.6 0.6 0.6 0.6 2.5 2.5 3.8 3.8 3.8
Max. Chiller Water Flow l/s 9.5 9.5 9.5 9.5 12.6 12.6 18.9 18.9 18.9
Water Connections Size, in 2 2 2 2 3 3 3 3 3
