JOHNSON CONTROLS
21
SECTION 2 – PRODUCT DESCRIPTION
FORM 150.67-NM2
ISSUE DATE: 01/31/2019
2
LD11463
KEYPAD AND DISPLAY
UNIT SWITCH
COMPRESSOR CONTACTORS
USER TERMINAL BLOCK
CIRCUIT BREAKER
FIGURE 2 - CONTROL/POWER PANEL COMPONENTS SINGLE SYSTEM UNITS
CONTROL - POWER PANEL COMPONENTS YCAL0019 – 0033
