York YVWA User Manual

JOHNSON CONTROLS
151
SECTION 8 - TROUBLESHOOTING
FORM 201.30-ICOM1 (519)
ISSUE DATE: 05/22/2019
8
TABLE 49 - PRESSURE TRANSDUCER
EVAP PRESSURE
(125 PSIG)
ECONOMIZER PRESSURE
(275 PSIG)
DISCHARGE, CONDENSER, OIL PRESSURE
(400 PSIG)
PRESSURE VOLTAGE PRESSURE VOLTAGE PRESSURE VOLTAGE PRESSURE VOLTAGE PRESSURE VOLTAGE
0 0.5 0 0.5 180 3.12 0 0.5 180 2.3
5 0.66 5 0.57 185 3.19 5 0.55 185 2.35
10 0.82 10 0.65 190 3.26 10 0.6 190 2.4
15 0.98 15 0.72 195 3.34 15 0.65 195 2.45
20 1.14 20 0.79 200 3.41 20 0.7 200 2.5
25 1.3 25 0.86 205 3.48 25 0.75 205 2.55
30 1.46 30 0.94 210 3.55 30 0.8 210 2.6
35 1.62 35 1.01 215 3.63 35 0.85 215 2.65
40 1.78 40 1.08 220 3.7 40 0.9 220 2.7
45 1.94 45 1.15 225 3.77 45 0.95 225 2.75
50 2.1 50 1.23 230 3.85 50 1 230 2.8
55 2.26 55 1.3 235 3.92 55 1.05 235 2.85
60 2.42 60 1.37 240 3.99 60 1.1 240 2.9
65 2.58 65 1.45 245 4.06 65 1.15 245 2.95
70 2.74 70 1.52 250 4.14 70 1.2 250 3
75 2.9 75 1.59 255 4.21 75 1.25 255 3.05
80 3.06 80 1.66 260 4.28 80 1.3 260 3.1
85 3.22 85 1.74 265 4.35 85 1.35 265 3.15
90 3.38 90 1.81 270 4.43 90 1.4 270 3.2
95 3.54 95 1.88 275 4.5 95 1.45 275 3.25
100 3.7 100 1.95 100 1.5 280 3.3
105 3.86 105 2.03 105 1.55 285 3.35
110 4.02 110 2.1 110 1.6 290 3.4
115 4.18 115 2.17 115 1.65 295 3.45
120 4.34 120 2.25 120 1.7 300 3.5
125 4.5 125 2.32 125 1.75 305 3.55
130 2.39 130 1.8 310 3.6
135 2.46 135 1.85 315 3.65
140 2.54 140 1.9 320 3.7
145 2.61 145 1.95 325 3.75
150 2.68 150 2 330 3.8
155 2.75 155 2.05 335 3.85
160 2.83 160 2.1 340 3.9
165 2.9 165 2.15 345 3.95
170 2.97 170 2.2 350 4
175 3.05 175 2.25 355 4.05
