JOHNSON CONTROLS
42
FORM 201.30-ICOM1 (519)
ISSUE DATE: 05/22/2019
SECTION 3 - HANDLING, STORAGE, INSTALLATION AND REASSEMBLY
Refer to Table 4 on page 32 for Torque Specications.
LD17760
136/145 Compressor Ports
J
Oil Return
from Oil Separator
H
Oil Return
from Eductor
J
Oil Return
from Oil Separator
H
Oil Return
from Eductor
Oil
Pressure
Transducer
Oil
Pressure
Transducer
151 Compressor Ports
FIGURE 20 - TRANSDUCER, EDUCTOR AND OIL RETURN PIPING
Refer to Table 4 on page 32 for Torque Specications.
LD17761
Piping to
Compressor
O
FIGURE 21 - OIL SUPPLY PIPING
