JOHNSON CONTROLS
62
FORM 201.30-ICOM1 (519)
ISSUE DATE: 05/22/2019
SECTION 3 - HANDLING, STORAGE, INSTALLATION AND REASSEMBLY
FIGURE 38 - POWER CONNECTIONS
VSD CONTROL PANEL
STANDARD
CONTROL
TRANSFORMER
UNIT CONTROLS
PE
LINE
REACTOR
CIRCUIT BREAKER
OPTION AVAILABLE
FIELD PROVIDED
UNIT POWER
SUPPLY
SEE NOTE 1
NON-FUSED
DISCONNECT SWITCH
NOTES:
1.
------- Dashed Line = Field Provided Wiring
INVERTER
LD16428A
