4 - 32 LI4278 Product Reference Guide
PIN Code
Parameter # 552
To set and store a PIN code (e.g., password) on the linear imager scanner to connect to the host:
1. Scan the Set & Store PIN Code bar code below.
2. Scan five alphanumeric programming bar codes using the alphanumeric bar codes beginning on page E-1.
3. Scan End of Message on page E-7.
The default PIN code is 12345.
If the linear imager scanner communicates with a host with security enabled, synchronize the PIN codes on the
linear imager scanner and host. To achieve this, connect the linear imager scanner to the host when setting the
PIN codes. If the linear imager scanner is not connected to a host, the PIN code change only takes affect on
the linear imager scanner. If security is required between the linear imager scanner and host, and the PIN
codes do not match, pairing fails.
Variable PIN Code
Parameter # 608
When switching to Cradle Host mode with authentication enabled, scan Static PIN Code below to avoid
entering the PIN code manually. The PIN stored in memory is used. Scan the Variable PIN Code below to
manually enter a PIN code with each connection.
The default PIN code is the user-programmed PIN set and stored above. Typically, however, HID connections
require entering a Variable PIN Code. If, when attempting connection, the application presents a text box that
includes a PIN, scan the Variable PIN Code bar code, then re-attempt connection. When you hear a beep
indicating the linear imager scanner is waiting for an alphanumeric entry, enter the provided variable PIN using
the Alphanumeric Keyboard on page E-1, then scan End of Message on page E-7 if the code is less than 16
characters. The linear imager scanner discards the variable PIN code after connection.
NOTE An extended 16 character PIN code is available for additional security with Open Bluetooth
(SPP and HID).
Set and Store PIN Code
*Static PIN Code
(0)
Variable PIN Code
(1)
