Zebra LI4278 Product Reference Guide

CHAPTER 8 USB INTERFACE
Introduction
This chapter provides instructions for programming the cradle to interface with a USB host. The linear imager
scanner cradle connects directly to a USB host, or a powered USB hub. The USB host can power the cradle
and recharge the linear imager scanner battery, but this charging method has limitations. See Supplying Power
to the CR0078-S/CR0008-S Cradle on page 1-8.
Throughout the programming bar code menus, default values are indicated with asterisks (
*).
*North American Standard USB Keyboard
Feature/Option
*Indicates Default
NOTE The CR0078-S cradle has the ability to be powered by the USB port instead of an external power supply.
The CR0078-P can only receive power via an external power supply.

Zebra LI4278 Specifications

General

Wavelength	617 nm
Read rate (max)	547 reads/s
Decoding standards	UPC/EAN, UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN, UCC Coupon, ISBT 128, Code 39, Code 93, Matrix 2/5, Interleavd 2/5, Discrete 2/5, Codabar, MSI Chinese 2/5, GS1
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Bluetooth	Yes
Bluetooth version	2.1+EDR
Standard interfaces	USB, RS-232, RS-485
Operating time	4320 min
Maximum operating distance	100 m
Certification	FCC, ICES, IEC, RoHS, EN, UL
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	186 mm
Width	70 mm
Height	98 mm
Weight	224 g
