Zebra LI4278 Product Reference Guide

8 - 4 LI4278 Product Reference Guide
USB Parameter Defaults
Table 8-1 lists the defaults for USB host parameters. If any option needs to be changed, scan the appropriate
bar code(s) provided in the Parameter Descriptions section beginning on page 8-5.
NOTE See Appendix A, STANDARD DEFAULT PARAMETERS for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 8-1 USB Host Default Table
Parameter Default
Page
Number
USB Host Parameters
USB Device Type HID Keyboard Emulation 8-5
Symbol Native API (SNAPI) Status Handshaking Enable 8-6
USB Country Keyboard Types (Country Codes) North American
Standard USB Keyboard
8-7
USB Keystroke Delay No Delay 8-9
USB CAPS Lock Override Disable 8-9
USB Ignore Unknown Characters Send 8-10
USB Convert Unknown to Code 39 Disable 8-10
Emulate Keypad Disable 8-11
Emulate Keypad with Leading Zero Disable 8-11
Quick Keypad Emulation Disable 8-12
USB FN1 Substitution Disable 8-12
Function Key Mapping Disable 8-13
Simulated Caps Lock Disable 8-13
Convert Case No Case Conversion 8-14
USB Static CDC Enable 8-14
Ignore Beep Disable 8-15
Ignore Bar Code Configuration Disable 8-15
USB Polling Interval 8 msec 8-17

Zebra LI4278 Specifications

General

Wavelength	617 nm
Read rate (max)	547 reads/s
Decoding standards	UPC/EAN, UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN, UCC Coupon, ISBT 128, Code 39, Code 93, Matrix 2/5, Interleavd 2/5, Discrete 2/5, Codabar, MSI Chinese 2/5, GS1
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Bluetooth	Yes
Bluetooth version	2.1+EDR
Standard interfaces	USB, RS-232, RS-485
Operating time	4320 min
Maximum operating distance	100 m
Certification	FCC, ICES, IEC, RoHS, EN, UL
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	186 mm
Width	70 mm
Height	98 mm
Weight	224 g
