Zebra LI4278 Product Reference Guide

GETTING STARTED 1 - 7
Linear Imager Scanner Cradle
The scanner cradles (CR0078-S and CR0078-P) serve as a stand, charger, and host interface for the linear
imager scanner. The cradle sits on a desktop. The CR0078-S cradle can also be mounted on a vertical surface
(such as a wall). For more information about mounting options and procedures, refer to the documentation
included with the cradle.
The CR0078-S cradle is available as a charging cradle with a radio and as a charge-only cradle. The
CR0078-P cradle is only available as a charging cradle with a radio. The differences between the two versions
are as follows:
• Charging cradle with radio: When the cordless linear imager scanner is paired to the cradle, all
communication between the linear imager scanner and the host computer is accomplished through the
cradle. Each bar code contains programming instructions or other data unique to the bar code pattern.
The linear imager scanner is paired to the cradle and transmits bar code data to the cradle via Bluetooth
Technology Profile Support. The cradle then sends that information via an interface cable to the host
computer for interpretation.
• Charge-only cradle: This cradle serves as a stand and battery charger. It does not contain a radio and
has no communication capability.
Table 1-2 outlines several main differences between the CR0078-S and CR0078-P cradles.
NOTE For more information about communication between the linear imager scanner, cradle and host, see
Chapter 4, RADIO COMMUNICATIONS.
Table 1-2 Cradle Features
Feature CR0078-S CR0078-P
Scanning Hand-Held scanning Hands-Free or Hand-Held scanning
Bluetooth Bluetooth or Charge Only (CR0008-S) Bluetooth
Pairing Pair up to 3 scanners per cradle Pair up to seven scanners per cradle
Paging Not available Ability to page misplaced scanner(s)
Charging Can charge via host power, if available,
or with optional 5V power supply.
Requires 12V power supply
Interfaces Supports most commonly used interfaces
(see Technical Specifications on page 3-9
for detailed list)
Supports most commonly used interfaces
with the exception of Wand Emulation,
Scanner Emulation and Synapse
USB Cable Standard universal USB cable Requires universal cables with shielded
modular plugs

Zebra LI4278 Specifications

General

Wavelength	617 nm
Read rate (max)	547 reads/s
Decoding standards	UPC/EAN, UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN, UCC Coupon, ISBT 128, Code 39, Code 93, Matrix 2/5, Interleavd 2/5, Discrete 2/5, Codabar, MSI Chinese 2/5, GS1
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Bluetooth	Yes
Bluetooth version	2.1+EDR
Standard interfaces	USB, RS-232, RS-485
Operating time	4320 min
Maximum operating distance	100 m
Certification	FCC, ICES, IEC, RoHS, EN, UL
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	186 mm
Width	70 mm
Height	98 mm
Weight	224 g
