Zebra LI4278 Product Reference Guide

KEYBOARD WEDGE INTERFACE 6 - 3
Keyboard Wedge Parameter Defaults
Table 6-1 lists the defaults for Keyboard Wedge host parameters. To change any option, scan the appropriate
bar code(s) in the Keyboard Wedge Host Parameters section beginning on page 6-4.
NOTE See Appendix A, STANDARD DEFAULT PARAMETERS for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 6-1 Keyboard Wedge Host Default Table
Parameter Default
Page
Number
Keyboard Wedge Host Parameters
Keyboard Wedge Host Type
IBM PC/AT& IBM PC Compatibles
6-4
Country Types (Country Codes) North American 6-5
Ignore Unknown Characters Send 6-7
Keystroke Delay No Delay 6-7
Intra-Keystroke Delay Disable 6-8
Alternate Numeric Keypad Emulation Disable 6-8
Caps Lock On Disable 6-9
Caps Lock Override Disable 6-9
Convert Wedge Data No Convert 6-10
Function Key Mapping Disable 6-10
FN1 Substitution Disable 6-11
Send and Make Break Send 6-11

Zebra LI4278 Specifications

General

Wavelength	617 nm
Read rate (max)	547 reads/s
Decoding standards	UPC/EAN, UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN, UCC Coupon, ISBT 128, Code 39, Code 93, Matrix 2/5, Interleavd 2/5, Discrete 2/5, Codabar, MSI Chinese 2/5, GS1
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Bluetooth	Yes
Bluetooth version	2.1+EDR
Standard interfaces	USB, RS-232, RS-485
Operating time	4320 min
Maximum operating distance	100 m
Certification	FCC, ICES, IEC, RoHS, EN, UL
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	186 mm
Width	70 mm
Height	98 mm
Weight	224 g
