Zebra LI4278 Product Reference Guide

SYMBOLOGIES 11 - 9
Decode UPC/EAN/JAN Supplementals
Parameter # 16
Supplementals are bar codes appended according to specific format conventions (e.g., UPC A+2, UPC E+2,
EAN 13+2). The following options are available:
• If you select Ignore UPC/EAN with Supplementals, and the linear imager scanner is presented
with a UPC/EAN plus supplemental symbol, the linear imager scanner decodes UPC/EAN and ignores
the supplemental characters.
• If you select Decode UPC/EAN with Supplementals, the linear imager scanner only decodes UPC/EAN
symbols with supplemental characters, and ignores symbols without supplementals.
• If you select Autodiscriminate UPC/EAN Supplementals, the linear imager scanner decodes
UPC/EAN symbols with supplemental characters immediately. If the symbol does not have a
supplemental, the linear imager scanner must decode the bar code the number of times set via
UPC/EAN/JAN Supplemental Redundancy on page 11-12 before transmitting its data to confirm that
there is no supplemental.
• If you select one of the following Supplemental Mode options, the linear imager scanner immediately
transmits EAN-13 bar codes starting with that prefix that have supplemental characters. If the symbol
does not have a supplemental, the linear imager scanner must decode the bar code the number of times
set via UPC/EAN/JAN Supplemental Redundancy on page 11-12 before transmitting its data to confirm
that there is no supplemental. The linear imager scanner transmits UPC/EAN bar codes that do not have
that prefix immediately.
• Enable 378/379 Supplemental Mode
• Enable 978/979 Supplemental Mode
• Enable 977 Supplemental Mode
• Enable 414/419/434/439 Supplemental Mode
• Enable 491 Supplemental Mode
• Enable Smart Supplemental Mode - applies to EAN-13 bar codes starting with any prefix listed
previously.
• Supplemental User-Programmable Type 1 - applies to EAN-13 bar codes starting with a 3-digit
user-defined prefix. Set this 3-digit prefix using User-Programmable Supplementals on page 11-12.
• Supplemental User-Programmable Type 1 and 2 - applies to EAN-13 bar codes starting with either
of two 3-digit user-defined prefixes. Set the 3-digit prefixes using User-Programmable Supplementals
on page 11-12.
• Smart Supplemental Plus User-Programmable 1 - applies to EAN-13 bar codes starting with any
prefix listed previously or the user-defined prefix set using User-Programmable Supplementals on
page 11-12.
• Smart Supplemental Plus User-Programmable 1 and 2 - applies to EAN-13 bar codes starting with
any prefix listed previously or one of the two user-defined prefixes set using User-Programmable
Supplementals on page 11-12.
NOTE If you select 978/979 Supplemental Mode and are scanning Bookland EAN bar codes, see
Enable/Disable Bookland EAN on page 11-8 to enable Bookland EAN, and select a format using Bookland
ISBN Format on page 11-20.
NOTE To minimize the risk of invalid data transmission, select either to decode or ignore supplemental
characters.

Zebra LI4278 Specifications

General

Wavelength	617 nm
Read rate (max)	547 reads/s
Decoding standards	UPC/EAN, UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN, UCC Coupon, ISBT 128, Code 39, Code 93, Matrix 2/5, Interleavd 2/5, Discrete 2/5, Codabar, MSI Chinese 2/5, GS1
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Bluetooth	Yes
Bluetooth version	2.1+EDR
Standard interfaces	USB, RS-232, RS-485
Operating time	4320 min
Maximum operating distance	100 m
Certification	FCC, ICES, IEC, RoHS, EN, UL
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	186 mm
Width	70 mm
Height	98 mm
Weight	224 g
