235
ESSENTIAL TECHNICAL PARAMETERS
FORWARD TRAVEL SPEED OF THE TRACTOR - 30 KM/H
Speed of the tractor in km/h at nominal
speed of the engine (2,200 rpm) and given
sizes of rear wheel tyres
Speed of dependent rear
output shaft 540/1000 at
nominal speed of the engine
(2,200 rpm)
Speed of dependent rear
output shaft 540/540E at
nominal speed of the engine
(2,200 rpm)
Gear
Multiplier
stage
16,9 - 34 18,4 -34 18,4 - 30 13,6 - 36 540 rpm 1000 rpm 540 rpm 540E rpm
4 Hi H 29.8 30.8 28.8 28.6 712.5 1344.4 1061.9 1344.4
L 23.0 23.8 22.2 22.1 712.5 1344.4 1061.9 1344.4
3 Hi H 20.5 21.2 19.8 19.7 490.5 925.5 731.0 925.5
L 15.8 16.3 15.3 15.2 490.5 925.5 731.0 925.5
2 Hi H 12.8 13.2 12.4 12.3 306.7 578.7 457.1 578.7
L 9.9 10.2 9.6 9.5 306.7 578.7 457.1 578.7
1 Hi H 8.9 9.2 8.6 8.5 211.7 399.4 315.4 399.4
L 6.8 7.1 6.6 6.6 211.7 399.4 315.4 399.4
4 Lo H 7.6 7.8 7.3 7.3 180.5 340.7 269.1 340.7
L 5.8 6.0 5.6 5.6 180.5 340.7 269.1 340.7
3 Lo H 5.2 5.4 5.0 5.0 124.3 234.5 185.2 234.5
L 4.0 4.1 3.9 3.8 124.3 234.5 185.2 234.5
2 Lo H 3.3 3.4 3.1 3.1 77.7 146.6 115.8 146.6
L 2.5 2.6 2.4 2.4 77.7 146.6 115.8 146.6
1 Lo H 2.2 2.3 2.2 2.2 52.3 98.7 77.9 98.7
L 1.7 1.8 1.7 1.7 52.3 98.7 77.9 98.7
Hi – road gears
Lo – reduced gears
H – higher stage of the multiplier
L – lower stage of the multiplier
