58
GETTING TO KNOW THE TRACTOR
P+11NH127b G153
SWITCHING ON OUTPUT SHAFT
DRIVE
This drive can be switched on using
switches on the right column of the cab-
in.
LEVER OF SHIFTING OF SPEED 540
(OR 540E) AND 1,000 RPM OF THE
REAR OUTPUT SHAFT
Shifting can be carried out when the trac-
tor is in standstill by pulling up or pushing
down the lever.
a - 1,000 min
-1
(or 540E min
-1
)
b - 540 min
-1
∗The tractor can be equipped optionally
by 6-, 8- or 21-groove termination of the
output shaft.
Shifting of 540 and 1,000 (or
540E) min
-1
is possible regard-
less to the number of grooves on
the installed termination. Speed
of the output shaft and type of the
termination shall be chosen de-
pending on the prescribed speed
of the aggregated machine.
