240
ESSENTIAL TECHNICAL PARAMETERS
OUTER CONTOUR AND TRACK WHEELING DIAMATER
front 1,610mm
Wheel track
rear 1,500mm
To the left (mm)
To the right
(mm)
Without engaged front driving axle (PHN) 11,850 11,380
Without engaged front driving axle with partial braking of
the inner rear wheel
9,880 9,650
With engaged front driving axle 12,570 12,130
Track diameter
(mm)
With engaged front driving axle with partial braking of the
inner rear wheel
8,750 8,580
Without engaged front driving axle 12,160 11,720
Without engaged front driving axle with partial braking of
the inner rear wheel
10,190 9,990
With engaged front driving axle 12,880 12,400
Contour diameter
(mm)
With engaged front driving axle with partial braking of the
inner rear wheel
9,060 8,920
