236
ESSENTIAL TECHNICAL PARAMETERS
BACKWARD TRAVEL SPEED OF THE TRACTOR - 30 KM/H
Speed of the tractor in km/h at nominal
speed of the engine (2,200 rpm) and given
sizes of rear wheel tyres
Speed of dependent rear
output shaft 540/1000 at
nominal speed of the engine
(2,200 rpm)
Speed of dependent rear
output shaft 540/540E at
nominal speed of the engine
(2,200 rpm)
Gear
Multiplier
stage
16,9 - 34 18,4 -34 18,4 - 30 13,6 - 36 540 ot 1000 ot 540 ot 540E ot
4 Hi H 31.7 32.8 30.6 30.4 757.9 1430.2 1129.6 1430.2
L 24.4 25.2 23.6 23.4 757.9 1430.2 1129.6 1430.2
3 Hi H 21.8 22.5 21.1 20.9 521.8 984.6 777.7 984.6
L 16.8 17.4 16.2 16.1 521.8 984.6 777.7 984.6
2 Hi H 13.6 14.1 13.1 13.1 326.2 615.6 486.2 615.6
L 10.5 10.9 10.1 10.1 326.2 615.6 486.2 615.6
1 Hi H 9.4 9.7 9.1 9.0 225.2 424.8 335.6 424.8
L 7.3 7.5 7.0 7.0 225.2 424.8 335.6 424.8
4 Lo H 8.0 8.3 7.8 7.7 192.1 362.4 286.2 362.4
L 6.2 6.4 6.0 5.9 192.1 362.4 286.2 362.4
3 Lo H 5.5 5.7 5.3 5.3 132.2 249.5 197.1 249.5
L 4.3 4.4 4.1 4.1 132.2 249.5 197.1 249.5
2 Lo H 3.5 3.6 3.3 3.3 82.7 156.0 123.2 156.0
L 2.7 2.8 2.6 2.6 82.7 156.0 123.2 156.0
1 Lo H 2.4 2.5 2.3 2.3 55.6 105.0 82.9 105.0
L 1.8 1.9 1.8 1.8 55.6 105.0 82.9 105.0
Hi – road gears
Lo – reduced gears
H – higher stage of the multiplier
L – lower stage of the multiplier
