35
GETTING TO KNOW THE TRACTOR
E113 E114 E115
DRIVER’S SEAT MARS SVRATKA
ADJUSTMENT ACCORDING TO THE
DRIVER’S WEIGHT
Cushioning of the seat is adjustable for
driver’s weight from 50 to 120kg. Ad-
justment is carried out using a rotary
square handle. Indicator of adjustment of
the weight can be found in a recess of
the seat rear cover. Cushioning stroke is
120mm.
Do not adjust during drive!
Risk of an accident!
LONGITUDINAL ADJUSTMENT
The seat can be adjusted longitudinally
within range ±75mm (11 positions) after
unlocking by the left lever.
VERTICAL ADJUSTMENT
The seat can be adjusted vertically by a
lever on the right side within range
±30mm from the middle position to both
marginal positions.
