ZIEHL-ABEGG ZA rec 4C Series User Manual

1
2
3 4
Cable breakthrough of ZArec4C 026/039
1 Power line
2 Cable digital inputs and outputs, cable temperature monitor brake resistor
3 Brake resistor cable
4 DC cable
5.4 Strain relief
5.4.1 ZArec4C 013
5.4.1.1 X-IN-OUT connection cable and ZApad cable strain relief
Strain relief by cable ties must be provided on the X-IN-OUT connection cable and the ZApad cable
(see fig.).
1.2 Strain relief by cable ties
Original operating instructions
ZArec4C Electrical installation
R-TBA14_03-GB 1817 Index 007 Part.-No. 00163436-GB
