14 Enclosure
14.1 Technical data for ZArec4C
ZArec4C 013 ZArec4C 026/039
Electrical data
Mains connection voltage [V] 3~ 400 +10 / -15 % 3~ 400 +10 / -15 %
Control voltage [V] 230
Mains frequency [
Hz] 50
(60 Hz auf Anfrage)
50
(60 Hz auf Anfrage)
Perm. mains asymmetry
≤ 3 % negative phase
sequence
≤ 3 % negative phase
sequence
Max. extractable power [kW] 13 26/39
Max. regenerative power [kW] 5 10/15
Max. regenerative power [A] 7.2 14.4/21.7
Duty cycle at rated current and clock frequency 16 kHz [%]
20 20
Rated current for 20 % switch-on duration and switching fre-
quency 16 kHz fixed
[A] 7 14.4/21.7
Max. operating current [A] 7 14.4/21.7
Power loss at rated current, switching frequency 16 kHz and
20% ED
[W] 500 989/1129
Power loss in standby [W] < 10,0 < 15
Switching frequency [kHz] 16 16
Max. terminal cross-section X2/X-DC, BR-ext/X-BR [mm
2
]
6 16
Max. terminal cross-section X1, X4 [mm
2
]
1.5 6
Internal diameter range screw cable glands brake resistance
cable, DC cable, power cable
[mm]
9...17
Internal diameter range screw cable gland control vo
ltage cable [mm] 4,5...10
Fuse protection
2 x 25 A flink, 900 VDC,
gPV, 10 x 38 mm
Ambient conditions
The user must ensure that the specified ambient conditions are
observed.
Protection rating
IP20
Ambient temperature for operation [°C] 0 to 55, from 40 °C power reduction by 1.66 % per
1 K temperature increase
Relative humidity [%] < 90 / condensation prohibited
Installation height [m über
NN]
bis 2000, ab 1000 m Leistungsreduzierung um
1 % pro 100 m
Storage and shipping temperature [°C] -20...+50
Degree of soiling (in acc. with DIN EN 61800-5-1)
2
P
hysical data
Weight [kg] 42,5 68/85
Dimensions h x w x d [mm] 398,7 x 871.5 x 128 828 x 376 x 190
Original operating instructions
ZArec4C Enclosure
R-TBA14_03-GB 1817 Index 007 Part.-No. 00163436-GB
5
9/64
