10.5 Delete error memory
The fault memory is wiped by means of an entry in the Statistic / ST_CLR=ON.
The following parameters are reset:
•
ST_LST (Error list)
•
ST_RES (Number of interruptions in the mains supply)
10.6 Error list
All error messages are stored in the Statistic / ST_LST menu (see "Error diagnosis / error memory"
chapter)
10.6.1 Masc-Funktion
Individual monitoring functions can be deactivated by an entry in the error mask (see chapter
"Parameter List/Monitorings Menu"). The appropriate error number must be entered in one of the error
masks 1-3 for this.
The maskable errors are marked in the error list with a point in thecolum n M.
CAUTION!
Warning!
The mask function may only be used for troubleshooting and error diagnostics. The corresponding
error cause must be eliminated to ensure continuous service of the ZArec4C!
Sequential errors can occur if errors are masked.
The masking deactivates important monitoring functions. This may result in dangerous operating
states or damage to the ZArec4C.
10.6.2 Block function
Blocks the ZArec4C and the frequency inverter if certain errors occur several times is succession. The
errors must occur in directly consecutive travel tests. The error counter is set to 0 when performing a
trouble-free travel.
Errors that lead to locking of the ZArec4C lead to a travel abort.
The locking functions can be parameterised in the Monitorings / MOD_ERR menu.
Errors which lead to locking of the ZArec4C are identified by a dot in the S column.
If the ZArec4C is locked, no operation is possible with the ZApad. The LED switches through RED-
GREEN-BLUE.
Error no. Error text Error cause M S
0 no error
error-free state
101
M
AIN_CON_DONT_-
CLOSE
Error: Mains contactor does not close
Remedy: Check control voltage at X4
●
102
MAIN_CON_DON-
T_OPEN
Error: Mains contactor does not open
●
103
MAIN_CON_INTER-
RUPT
Error: Mains contactor opened again after closing
Remedy: Check control voltage at X4
●
104 CA_TRIP_ZONE_UVW
Error: Overcurrent phase U, V or W
Cause: Phase failure or phase shift on the mains
●
105 OVERVOLTAGE
Error: Overvoltage
●
106 PLL_FAIL
Error: No synchronisation with the mains
●
107 BAD_GRID_1
Error: Mains fault type 1
●
108 BAD_GRID_2
Error: Mains fault type 2
There is a phase error for more than 20 ms!
●
109
CA_XINT1_ER-
R_I_UVW
Error: Overcurrent phase U, V or W
●
110 CA_XINT2_ERR_I_DC
Error: Overcurrent DC input current
30-s-restart pause.
●
111
CA_XINT3_ERR_U-
CE_UVW
Error: U_CE monitoring Phase U, V or W.
30-s-restart pause.
●
Original operating instructions
ZArec4C Error diagnosis
R-TBA14_03-GB 1817 Index 007 Part.-No. 00163436-GB
4
9/64
