Parameter Designation Value range
Factory set-
ting
BR_TYP Input of the used brake resistance
Off: no brake resistance used
BR11: Brake resistor type BR11-A
BR11+BR14: BR11 and BR14
BR14: Brake resistor type BR14
BR17-1: Brake resistor type BR17
BR25-1: Brake resistor type BR25
BR50:Brake resistor type BR50
Off
BR11
BR11+BR14
BR14
BR17
BR25
BR50
ZArec4C 013:
BR11
ZArec4C 026:
BR25
ZArec4C 039:
BR50
f_CL Input function of the input CL
ClrError: Reset the lock
LockRec: Locking of return feed function. This function is used
in conjunction with a three-phase UPS or if there is a failure of
individual phases. The energy is completely discharged via the
brake resistor.
ClrError
LockRec
LockRec
9.3 Monitoring menu
Confi guring the monitoring functions
Parameter Designation Value range
Factory set-
ting
MOD_ERR Behaviour of the ZArec4C in case of faults
Block function: In the event that successive errors are reported
but an error-free run is performed, you have the option of block-
ing the ZArec4C. The error output (/ERR) stays open. The
counter is set to 0 when an error-free run is performed.
Never: no locking function
Lock n.3: Locking function after 3 errors. The error output
(/ERR) drops out after the 2rd error.
Lock n.2: Locking function after 2 errors. The error output
(/ERR) drops out after the 2nd error.
Lock n.1: Locking function after 1 error. The error output (/ERR)
drops out after the 1st error.
The errors that lead to locking are marked accordingly in the
error list.
Never
Lock n.3
Lock n.2:
Lock n.1
Lock n.3
UDC_MIN Input of the minimum intermediate circuit voltage
If the value drops below this minimum value, an error message
is output.
100...500 V 450
MASK1 Error mask 1...3
Suppression of up to three error messages through configuring
the corresponding error number in an error mask
0...3999
0
MASK2
0
MASK3
0
9.4 Controller menu
Parameter Designation Value range
Factory set-
ting
U_DC_SR Speed with which the voltage of the intermediate circuit is in-
creased
100...1,500 V/s 1,000 V/s
9.5 Filter menu
Parameter Designation Value range
Factory set-
ting
LP_I_IN Frequency of the low pass for the input currrent
100...4000 Hz 100 Hz
Original operating instructions
ZArec4C Parameter list
R-TBA14_03-GB 1817 Index 007 Part.-No. 00163436-GB
