7.2.2 Menu and parameter navigation
Main page
ZArec4C 013
ZIEHL-ABEGGSE
SN: 09229587/0002
Phone: +49 794016308
- Press any key
Menu section
LCD & Password
->Basics
Controller
Filter
- Select required menu
C
onfirm menu selection
Parameter section
Base Setup
->U_GRID 0 V
U_DC_RF 0 V
Parameter selection
- Confirming parameter values
Changing parame-
t
er
Base Setup
|
-
" U_GRID 0V
|
-
" 400
Rated mains voltage
- Enter / select parameter value.
- Confirm value
8 Start-up
8.1 Safety instructions
CAUTION!
Warning!
Incorrectly wired connections can destroy the electrical/electronic components.
Electrostatic discharges can be hazardous to the electronic components and lead to errors in the
software.
You must comply with the following points to prevent damage to the ZArec4C or life-threatening
injuries when commissioning the ZArec4C:
•
The start-up of the ZArec4C may only be carried out by qualified persons under consideration of
the safety instructions.
•
Before starting work, make sure all tools and external parts have been removed from the ZArec4C.
•
Activate all safeguards and the emergency-off switches before commissioning.
•
Make sure no unauthorized persons are in the working area of the ZArec4C and that no other
persons can be endangered when the ZArec4C is started up.
•
inspect the electrical connections before the first start
•
Pay special attention to the protective measures (e.g. grounding, ...) for the electrostatically
endangered components.
•
Also read the chapter "General Safety Instructions".
Requirements for error-free commissioning:
•
Mains line is connected
•
Control voltage connected
•
if necessary, external brake resistance connected
•
Control cables connected
•
DC cable connected
8.2 Switching on the ZArec4C
Only applying the mains voltage the ZArec4C switches on after a self-test. The following display
appears:
ZArec4C
013
ZIEHL-ABEGGSE
SN: 09229587/0002
Phone: +49 794016308
Original operating instructions
ZArec4C Start-up
R-TBA14_03-GB 1817 Index 007 Part.-No. 00163436-GB
4
1/64
