9.6 Statistic menu
All statistical data can be called up in the Statistics menu. The data will be retained even after the
ZArec4C has been switched off. Reading out the error list and deleting the error memory are
described in the chapter "Error diagnosis".
Parameter Designation Value range
Factory set-
ting
ST_LST Error list
Cannot be set -
ST_H Operating hours
Cannot be set -
ST_DRV Number of trips
Cannot be set -
ST_RES Number of mains interruptions
Cannot be set -
ST_GE Number of mains disturbances
Cannot be set -
ST_SD Number of mains disturbances
Cannot be set -
ST_CLR Delete error memory
Deletion of ST_LST and ST_RES
On
Off
Off
RESET 99: Device reset, parameters are deleted and set to factory
settings.
Software version number (e.g.: Version 4.01 -> "401"): Reset
parameters ST_H, ST_DRV, ST_RES as well as the energy
meter and the system time. Recorder settings are overwritten by
factory settings.
0...65535 0
9.7 Memory Card menu
Contains the parameters for the various functions in association with a memory card.
Parameter Designation Value range
Factory set-
ting
SAV_ALL Saves error lists (.FLT) and printer lists (.PRT) to memory card
with serial number allocation.
The lists are saved in the ZR4/DEVICE/SerialNumber/LST fold-
er.
Off: no function
ON: Error list and printer list are saved on memory card. The
parameter jumps back to "Off" after saving.
On
Off
Off
SAV_PAR Save parameters to memory card (copy parameters in the case
of identical systems):
•
Parameter (.PA3) in the folder /ZR4/DEVICE/FORCE
Here, there is no serial number allocation. The data will be over-
written during each saving
Off: no function
ON: Parameters are saved on memory card. The parameter
jumps back to "Off" after saving.
On
Off
Off
LOD_PAR Load parameters from memory card to the ZArec4C (copy pa-
rameters in the case of identical systems)
Input 27: Parameters (.PA3) are loaded from the /ZR4/DEVICE/-
FORCE folder into the ZArec4C. The parameter jumps back to
"Off" after loading.
0...27 0
Original operating instructions
ZArec4C Parameter list
R-TBA14_03-GB 1817 Index 007 Part.-No. 00163436-GB
