9.8 MMC-Recorder menue
You have the option of performing measurements on the ZArec4C using a memory card without the
need for a notebook. The measurement is configured in the MMC recorder menu.
Parameter Designation Value range
Factory set-
ting
REC_MOD Recorder settings
Off:Recorder is switched off
On: Recorder is active, the data are saved on the memory card
Stop&Shot: Manual stopping and saving of a measurement
which was started with MOD=ON". After saving the data on the
memory card, REC_MOD will set to "Off".
ZAmon: Mode for using ZAmon software
Off
On
Stop&Shot
ZAmon
ZAmon
9.9 Power section menu
Confi guration of the power component.
Parameter Designation Value range
Factory set-
ting
f_PWM_H Cycle frequency with which the fed back current is modulated
nicht einstellbar 16.0
U_BC_OF BC engagement voltage offset
5...15 V 5 V
ADJ_UDC Correction factor to synchronise the input voltages of the ZAdyn
and the ZArec4C intermediate circuit
0.950...1.050 1,0
FAN Setting of the speed of the internal fans
AUTO: Speed is adapted to the temperature of the power unit
ON 100%...ON 10%: Setting of the speed in per cent of the
maximum speed
OFF: internal fans deactivated
AUTO
On 100%...On
10%
Off
AUTO
FAN_T Temperature of the power unit at which the internal fans switch
on
The parameter only has an effect in the case of the ZArec4C
013.
28...45 °C 33
9.10 CAN menu
Activation of the ZArec4C by CANopenLift is not yet supported at the moment.
9.11 ZA-Intern menu
The ZA-Internal menu contains hidden parameters which only become visible after entering a pass-
word.
Parameter Designation Value range
Factory set-
ting
PW_S9 Password to show additional parameters
0...65535 0
Original operating instructions
ZArec4C Parameter list
R-TBA14_03-GB 1817 Index 007 Part.-No. 00163436-GB
4
5/64
