9.12 INFO menu
Serial-No - - - - - - - -
01
ZArec4C 013
SN: 06128298/0001
4.01 27054
Page 01: Serial-No.
Line 2:
Indication of the recuperation unit type and size:
Line 3:
Serial number/type consecutively numbered
Line 4:
Software version
ENERGY - - - - - - - - - -
0
2
W_R: 0.00 kWh
Page 02: ENERGY
total amount of fed back energy in kilowatt hours
Info POWER - - - - - - -
03
P_GRID: + 0.0kW
P_BC: + 0.0kW
Duty_BC: 0%
Page 03: Info POWER
L
ine 2:
power currently fed into the mains in kilowatts
Line 3:
power currently output via the brake resistance in kilowatts
Line 4:
Modulation of the brake resistance in per cent
Info DUTY 10 min - -
04
ED_REC_ACTIVE:
0%
ED_REC_PWM_ON: 0%
LOAD_BR(120s): 0%
Page 04: Info DUTY 10 Min
On time during the last 10 minutes
Line 2:
On time of the return feed mode
Line 3:
On time of the PWM unit
Line 4:
Brake resistor utilisation during the last 120 seconds
READ_INFB - - - - - - - -
0
5
WAIT_START_BC
no error
INFB_ERROR
Page 05:
Line 1:
Return feed status
Line 2:
BR activation status
Line 3:
Error text
Line 4:
Message text
Info STATE - - - - - - -
0
6
STAT_RS: 70 Msg: 0
STAT_BC:110 Err: 0
Udc: 547V IN:545V
Page 06:
L
ine 2:
STAT_RS: Return feed status
Msg: Message number
Line 3:
STAT_BC: BR activation status
Err: Error number
Line 4:
Udc: ZArec4C intermediate circuit voltage
IN: Voltage present at the connection terminal to which the ZAdyn intermediate circuit is
connected
Original operating instructions
ZArec4C Parameter list
R-TBA14_03-GB 1817 Index 007 Part.-No. 00163436-GB
4
6/64
