User Manual
30
5.6 PTZ Control
Picture 5-55
Click the [
] icon to enter into [PTZ control] menu shown as Picture5-54. Now user can control
the camera with Pan, Tilt and Zoom capabilities.
Click [Zoom-/+] button to zoom in / out the image; Click [Focus -/+] button to focus the image; Click
[Iris -/+] button adjust iris to open or close.
Cruise Set
Open auto cruise function on PTZ setting menu if you want to setup cruise function (system default:
off), and set up cruise channel, cur point and total quantity and stop time etc
Total: set up pre-set bit quantity
Cur Point: indicates starting point cruised. System default point is 01. the model support up to
255 pre-set bit.
Stop time: sets the stop time at each point
GOTO: allow you go to a specific preset point.
Set: allow you set a set of specific preset points of a PTZ camera.
1. Select a camera you desire to set a preset point;
2. Adjust the camera in a desired direction;
3. Click [Set] to set the point as preset point;
4. Click [Save] to save the preset point;
5. Follow the above step to add one more preset point.
Save: save all the preset points
Clean: allow you delete one selected preset.
Note: Up to 254pre-sets per one camera can be stored. However, actual preset quantity differs
depending on PTZ performance.
5.7 Record search
You could enter into [Record Search] menu from Pop-up menu conveniently and quickly and
search/playback the record histories. We introduced Record search details previously in chapter 5.2.4.
5.8 Mute
You are allowed to click the icon [ ] to control the volume of DVR.
5.9 Record
You can start manual record function, or you also can click [Rec.] button on the Front panel or
Remote controller to activate manual record. Please stop record manually once you activate manual
record.
We introduced setting PTZ
parameters previously in chapter
5.2.5.3. Here we will discuss how
to operate PTZ controls.
