User Manual
34
：Snapshot function: allow you capture the live images and save it to a specified position. The image
should be saved as *.bmp format.
: clicking the icon will close/open the current channel’s live mode
Or click the right key of mouse on each <Live> window to pop up the interface shown as Picture 6-4.
Picture 6-4
：CH Display mode
：Allow you open all the <live> channels.
：Allow you close all the <live> channels.
：Display previous channels
：Display next channels
：Click the icon to enlarge current window to full screen; right-click to pop-up menu options, now
allow you select <Exit full screen>
6.3.1.2
PTZ Control
Picture 6-5
Show bit rate: show current bit rate;
Original Proportions: show original proportions.
① PTZ moving Direction control: allow you control PTZ
camera’s direction. And the middle button is called
[Auto-cruise] button.
②
PTZ speed control bar
③ : Iris, Focus and Zoom control
○
4 ：Preset setting/clear; Start cruise /stop cruise
