Figure 3-13
To delete an item in the setup list, perform the following steps:
1. Choose Network Setting > LAN Settings.
2. Choose the item to be deleted, and click Delete.
3.6 DMZ Settings
If the demilitarized zone (DMZ) is enabled, the packets sent from the WAN are directly sent to a
specified IP address on the LAN before being discarded by the firewall.
To set DMZ, perform the following steps:
1. Choose Network Setting > DMZ Settings.
2. Set DMZ to Enable.
3. (Optional) Set ICMP Redirect to Enable.
4. Set Host address.
This IP address must be different from the IP address set on the LAN Host Settings
page, but they must be on the same network segment.
5. Click Submit. As shown in Figure 3-14.
Figure 3-14
3.7 Static Route
3.7.1 Add Static Route
To add a static route, perform the following steps:
