ABB ACS550-01 User Manual

2 ACS550 User’s Manual
ACS550 Drive Manuals
The Industrial
IT
wordmark and Product names in the form
Drive
IT
are registered or pending trademarks of ABB.
CANopen is a registered trademark of CAN in Automation
e.V.
ControlNet is a registered trademark of ControlNet
International.
DeviceNet is a registered trademark of Open DeviceNet
Vendor Association.
DRIVECOM is a registered trademark of DRIVECOM User
Organization.
Interbus is a registered trademark of Interbus Club.
LonWorks is a registered trademark of Echelon Corp.
Metasys is a registered trademark of Johnson Controls Inc.
Modbus and Modbus Plus are registered trademarks of
Schneider Automation Inc.
Profibus is a registered trademark of Profibus Trade Org.
Profibus-DP is a registered trademark of Siemens AG.
GENERAL MANUALS
ACS550-01/U1 User's Manual (0.75…110 kW) /
(1…150 HP)
• Safety
•Installation
• Start-Up
• Embedded Fieldbus
• Fieldbus Adapter
• Diagnostics
• Maintenance
• Technical Data
ACS550-02/U2 User's Manual (110…355 kW) /
(150…550 HP)
• Safety
•Installation
• Start-Up
• Diagnostics
• Maintenance
• Technical Data
ACS550 Technical Reference Manual
(available in electronic format only)
• Detailed Product Description
– Technical product description including Dimensional
drawings
– Cabinet mounting information including power
losses
– Software and control including complete parameter
descriptions
– User interfaces and control connections
– Complete options descriptions
– Spare parts
–Etc.
• Practical Engineering Guides
– PID & PFC engineering guides
– Dimensioning and sizing guidelines
– Diagnostics and Maintenance information
–Etc.
OPTION MANUALS
(Fieldbus Adapters, I/O Extension Modules etc., manuals
delivered with optional equipment)
Relay Output Extension Module (typical title)
•Installation
• Start-Up
• Diagnostics
• Technical Data
© 2004 ABB Inc. All Rights Reserved.

ABB ACS550-01 Specifications

General

Brand	ABB
Model	ACS550-01
Category	Controller
Language	English
