ACS550 User’s Manual 215
Technical Data
Technical Data
Ratings
By type code, the table below provides ratings for the ACS550 adjustable speed AC
drive, including:
• IEC ratings
• NEMA ratings (shaded columns)
•Frame size
Ratings, 208…240 Volt Drives
Abbreviated column headers are described in “Symbols” on page 216.
Type Code Normal Use Heavy-Duty Use
Frame
Size
ACS550-x1-
see below
I
2N
A
P
N
kW
P
N
HP
I
2hd
A
P
hd
kW
P
hd
HP
Three-phase supply voltage, 208…240 V
-04A6-2 4.6 0.75 1.0 3.5 0.55 0.75 R1
-06A6-2 6.6 1.1 1.5 4.6 0.75 1.0 R1
-07A5-2 7.5 1.5 2.0 6.6 1.1 1.5 R1
-012A-2 11.8 2.2 3.0 7.5 1.5 2.0 R1
-017A-2 16.7 4.0 5.0 11.8 2.2 3.0 R1
-024A-2 24.2 5.5 7.5 16.7 4.0 5.0 R2
-031A-2 30.8 7.5 10.0 24.2 5.5 7.5 R2
-046A-2 46.2 11.0 15.0 30.8 7.5 10.0 R3
-059A-2 59.4 15.0 20.0 46.2 11.0 15.0 R3
-075A-2 74.8 18.5 25.0 59.4 15.0 20.0 R4
-088A-2 88.0 22.0 30.0 74.8 18.5 25.0 R4
-114A-2 114 30.0 40.0 88.0 22.0 30.0 R4
-143A-2 143 37.0 50.0 114 30.0 40.0 R6
-178A-2 178 45.0 60.0 150 37.0 50.0 R6
-221A-2 221 55.0 75.0 178 45.0 60.0 R6
-248A-2 248 75.0 100 192 55.0 75.0 R6
