EtherNet/IP – Communication protocol 227
 Fieldbus configuration object, class 91h
The fieldbus configuration object allows you to configure the
fieldbus configuration groups without the need to know the drive-
specific groups associated with the configuration groups.
Note: When you use the fieldbus configuration object to update the
fieldbus configuration groups, changes to the fieldbus configuration
will only take effect when a reset service is requested of the
Identity Object, the module is powered up the next time or when a
‘Fieldbus Adapter parameter refresh’ is given.
Class attributes
Instance #1: FENA-01/-11/-21 configuration parameters
group A (group 1)
The actual parameter group number depends on the drive type.
Group A (group 1) corresponds to:
• parameter group 51 in ACS355, ACSM1, ACS850 and
ACQ810
• parameter group 51 in ACS880 and ACS580 if the adapter is
installed as fieldbus adapter A or group 54 if the adapter is
installed as fieldbus adapter B.
# Attribute
name
Services Description Data
type
1 Revision Get Revision of the Configuration
Object
Array of
UINT8
# Attribute name Services Description Data
type
1 Configuration Group
A (Group 1) -
Parameter 1
Get, Set See 01 FBA TYPE on
page 117.
UINT16
2 Configuration Group
A (Group 1) -
Parameter 2
Get, Set See 02 PROTOCOL/
PROFILE on page 117.
UINT16
3 Configuration Group
A (Group 1) -
Parameter 3
Get, Set See 03 COMM RATE
on page 118.
UINT16
