Modbus/TCP – Start-up 51
FENA-01/-11-/21 configuration parameters – group A (group 1)
Note: The actual parameter group number depends on the drive
type. Group A (group 1) corresponds to:
• parameter group 51 in ACS355, ACSM1, ACS850 and
ACQ810
• parameter group 51 in ACS880 and ACS580 if the adapter is
installed as fieldbus adapter A or group 54 if the adapter is
installed as fieldbus adapter B.
No. Name/Value Description Default
01 FBA TYPE Read-only. Shows the fieldbus adapter type as
detected by the drive. The value cannot be
adjusted by the user.
If the value is 0 = None, the communication
between the drive and the module has not
been established.
128 =
ETHER-
NET
02 PROTOCOL/
PROFILE
Selects the application protocol and
communication profile for the network
connection.
The selections available for Modbus
communication are listed below.
0 =
MB/TCP
ABB C
ACS355:
FB PAR 2
ACSM1:
FBA PAR2
ACS850/ACQ810:
FBA par2
ACS880/ACS580:
Protocol/Profile
0 = MB/TCP ABB C Modbus/TCP: ABB Drives profile - Classic
1 = MB/TCP ABB E Modbus/TCP: ABB Drives profile - Enhanced
2 = MB/TCP T16 Modbus/TCP: Transparent 16-bit profile
3 = MB/TCP T32 Modbus/TCP: Transparent 32-bit profile
4 = MB/UDP ABB C Modbus over UDP: ABB Drives profile - Classic
5 = MB/UDP ABB E Modbus over UDP: ABB Drives profile -
Enhanced
6 = MB/UDP T16 Modbus over UDP: Transparent 16-bit profile
7 = MB/UDP T32 Modbus over UDP: Transparent 32-bit profile
