64 Modbus/TCP – Start-up
 Parameter setting examples – ACS355
Speed and torque control using the ABB Drives –
Enhanced communication profile
This example shows how to configure a speed and torque control
application that uses the ABB Drives - Enhanced profile. In
addition, some application-specific data is added to the
communication.
The start/stop commands and reference are according to the ABB
Drives profile. For more information, see section ABB Drives
communication profile on page 87.
When Reference 1 (REF1) is used, a reference value of ±20000
(decimal) corresponds to the reference set with parameter 1105
REF1 MAX in the forward and reverse directions.
When Reference 2 (REF2) is used, a reference value of ±10000
(decimal) corresponds to the reference set with parameter 1108
REF2 MAX in the forward and reverse directions.
The minimum and maximum 16-bit integer values that can be
given through the fieldbus are -32768 and 32767 respectively.
The table below gives the recommended drive parameter settings.
Output data Modbus
register
Input data Modbus
register
Control word (4)00001 Status word (4)00051
Speed reference (4)00002 Speed actual value (4)00052
Torque reference (4)00003 Torque actual value (4)00053
Constant speed 1
1)
(4)00004 Power
1)
(4)00054
Constant speed 2
1)
(4)00005 DC bus voltage
1)
(4)00055
1)
Example
Drive parameter Setting for ACS355
drives
Description
9802 COMM PROT SEL 4 = EXT FBA Enables communication
between the drive and the
fieldbus adapter module.
5101 FBA TYPE ETHERNET
1)
Displays the type of the fieldbus
adapter module.
