ABB PVI-6.0-TL-OUTD User Manual

- 20 -
000430BG
2 - Characteristics
Bracket dimensions
The wall mounting bracket dimensions are expressed in mm and inches
50.0 mm
1.96 in
8.0 mm
0.31 in
25.0 mm
0.98 in
7.0 mm
0.28 in
8.0 mm
0.31 in
1.5 mm
0.06 in
64.0 mm
2.52 in
257.5 mm
10.14 in
459.5 mm
18.09 in
515.0 mm
20.28 in
100.0 mm
3.94 in
315.0 mm
12.40 in
90.5 mm
3.56 in
55.5 mm
2.19 in
