ABB PVI-6.0-TL-OUTD User Manual

- 37 -
000436AG
4 - Lifting and transport
List of components supplied
Supplied with the inverter are all the components required to correctly
install and connect the inverter
Components available for all models Qty
Bracket for wall fastening 1
Plugs and screws for wall mounting 5 + 5
D.18 washer 5
M40 Cable Gland 1
M20 Cable Gland 1
Two-hole gasket for M20 signal cable glan-
ds and cap
1 + 1
Jumpers for conguration of the parallel in-
put channels
2
Connector for connecting the congurable
relay
2
Connector for the connection of the com-
munication and control signals
2
Quick t connectors (female)
For -S models: 4 pieces
For standard and -FS
models: 6 pieces
Quick t connectors (male)
For -S models: 4 pieces
For standard and -FS
models: 6 pieces
Male key TORX TX25 1
In addition to what is explained in this guide, the safety and installation information provided in the installation manual must be read and followed.
The technical documentation and the interface and management software for the product are available at the website.
