ABB PVI-6.0-TL-OUTD User Manual

- 56 -
000440AG
5 - Installation
Communication and control board
19
20
18
Ref.
inverter
Ref.
manual
Description
ALARM
18
Connection to the multi-function relay (ALARM)
REMOTE
18
Connection to the remote ON/OFF (REMOTE)
RS485
18
Connection of the RS485 (PC) line (RS485)
RS485 (A)
19
Connection of the RS485 (PC) line on RJ45 connector
RS485 (B)
19
Connection of the RS485 (PC) line on RJ45 connector
120 Ω TERM.
20
RS485 line (PC) termination resistance selector switch
