TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
194
Register
Address
Item Description
61038 51P-1 Curve Select (TYPE I) Unsigned 16 Bits
Range 0-12 (See Text Above)
61039 51P-1 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61040 51P-1 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 (X20) Time Dial
0<=Range<=10 (X20) Time Delay
61041 50P-1 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
61042 50P-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61043 50P-1 Time Dial/Time Delay Unsigned 16 Bits
Dial *10
Delay * 100
61044 150P-1 Curve Select Unsigned Integer 16 bits
See Table Above
61045 150P-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61046 150P-1 Time Dial Unsigned 16 Bits
0<=Range<=9.99 * 100
61047 46-1 Curve Select Byte Unsigned Integer 16 bits
See Table Above
61048 46-1 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61049 46-1 Time Dial/ Time Delay Unsigned 16 Bits
1<=Range<=12 * 10
0.2<=Range<= 0.4 *50
61050 51N-1 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
61051 51N-1 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61052 51N-1 Time Dial Unsigned 16 Bits
1<=Range <=20 /Delay Byte
0<=Range<=10 * 20 51N Time Multiplier
61053 50N-1 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
61054 51N-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61055 51N-1 Time Dial/Delay Setting Unsigned 16 Bits
Time Dial * 10
Delay * 100
61056 150N-1 Curve Select (TYPE II) Unsigned Integer 16 bits
See Table Above
61057 150N-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61058 150N-1 Time Delay Unsigned 16 Bits
0<=Range<=9.99 * 100
61059 87T-2 Tap Amp Setting Unsigned 16 Bits
2<=Range<=9 Amperes * 10
0.4<=Range <=1.8 * 50
61060 51P-2 Curve Select Byte (TYPE I) Unsigned 16 Bits (See Text Above)
61061 51P-2 Pickup Amp/OA Unsigned 16 Bits
To Next Page
