TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
204
Register
Address
Item Description
1<=Range <=20 /Delay Byte
0<=Range<=10 * 20 51N Time Multiplier
61309 50N-1 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
61310 51N-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61311 51N-1 Time Dial/Delay Setting Unsigned 16 Bits
Time Dial * 10
Delay * 100
61312 150N-1 Curve Select (TYPE II) Unsigned Integer 16 bits
See Table Above
61313 150N-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61314 150N-1 Time Delay Unsigned 16 Bits
0<=Range<=9.99 * 100
61315 87T-2 Tap Amp Setting Unsigned 16 Bits
2<=Range<=9 Amperes * 10
0.4<=Range <=1.8 * 50
61316 51P-2 Curve Select Byte (TYPE I) Unsigned 16 Bits (See Text Above)
61317 51P-2 Pickup Amp/OA Unsigned 16 Bits
1<=Range<=12 *10
0.2<=Range<=2.4 * 50
61318 51P-2 Time Dial/Delay Setting Unsigned 16 Bits
Dial : 1<=Range<=10 *20
Delay : 0<=Range<=10 * 20
61319 51P-2 Curve Select (TYPE I) Unsigned 16 Bits
Range 0-12 (See Text Above)
61320 51P-2 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61321 51P-2 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 (X20) Time Dial
0<=Range<=10 (X20) Time Delay
61322 51P-2 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
61323 51P-2 Pickup X Amps Unsigned 16 Bits
0.5<=Range<=20 Amp * 10 (See Note)
61324 51P-2 Time Dial/Time Delay Unsigned 16 Bits
Time Dial * 10
Time Delay * 20
61325 46-2 Curve Select (TYPE I) Unsigned Integer 16 bits
See Table Above
61326 46-2 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61327 46-2 Time Dial/ Time Delay Unsigned 16 Bits
1<=Range<=10 * 20
0<=Range<= 10 *20
61328 51G-2 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
61329 51G-2 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61330 51G-2 Time Dial/Time Delay Unsigned 16 Bits
1<=Ran
e <=10 * 20 : Time Dial
To Next Page
